| Specification list | MQ | |
| Optional colors |  | |
| Vehicle code | 91831379 | |
| L×W×H(mm) | 2140×870×1700 | |
| Wheel base(mm) | 1550 | |
| Wheel track(mm) | 670 | |
| Minumum ground clearance（mm） | ≥120 | |
| Minimum turning radius（m） | ≤2.5 | |
| Curb weight(kg) | 130 | |
| Max speed（km/h） | 25~28km/h | |
| Max slope of climb（%） | ≤15 | |
| Battery | Maximum60V32AH | |
| Motor, Electric power control（w） | 48/60V800W | |
| Driving mileage at efficient speed（km） | 45-65 | |
| Charging time（h） | 6～8h | |
| loading capacity | 1driver+2passenger | |
| Shock absorber type | Front shock absorber | φ31Hydraulic shock absorption |
| Rear shock absorber | Spring ahock absorber | |
| Wheel | Front/Rear tyre | Front 3.00-10 Rear 3.00-10 |
| Rim type | Aluminum wheel | |
| Steering type | Handlebar type | ● |
| Steering wheel type | － | |
| Brake | Front/Rear brake type | Front disc/Rear drum brake |
| Paking brake | Handbrake | |
| Rear axle | Rear axle structure | Split Rear axle |
| Functional configuration | Remote control key | ● |
| Alarm | ● | |
| Wiper | ● | |
| Seat | Foam seat | |
| Toughened front windshield | ● | |
| Vehicle lamps | Normal light（12V） | |
| High and low speed function | ● | |
| Back light | － | |
| LCD meter | ● | |
| Entertainment system | Speaker | － |
| Player | － | |
| MP3 | － | |
| Reversing image | － | |
| USB charging port | ● | |
| Accessory too | Instructions | － |
| Battery cable | ● | |
| Number of containers | SKD/纸箱 | 39Units/40HQ 12 Units/12GP |
| Note：●Standard ○Optional —none | ||
| Specification list | MQ | |
| Optional colors | | |
| Vehicle code | 91831379 | |
| L×W×H(mm) | 2140×870×1700 | |
| Wheel base(mm) | 1550 | |
| Wheel track(mm) | 670 | |
| Minumum ground clearance（mm） | ≥120 | |
| Minimum turning radius（m） | ≤2.5 | |
| Curb weight(kg) | 130 | |
| Max speed（km/h） | 25~28km/h | |
| Max slope of climb（%） | ≤15 | |
| Battery | Maximum60V32AH | |
| Motor, Electric power control（w） | 48/60V800W | |
| Driving mileage at efficient speed（km） | 45-65 | |
| Charging time（h） | 6～8h | |
| loading capacity | 1driver+2passenger | |
| Shock absorber type | Front shock absorber | φ31Hydraulic shock absorption |
| Rear shock absorber | Spring ahock absorber | |
| Wheel | Front/Rear tyre | Front 3.00-10 Rear 3.00-10 |
| Rim type | Aluminum wheel | |
| Steering type | Handlebar type | ● |
| Steering wheel type | － | |
| Brake | Front/Rear brake type | Front disc/Rear drum brake |
| Paking brake | Handbrake | |
| Rear axle | Rear axle structure | Split Rear axle |
| Functional configuration | Remote control key | ● |
| Alarm | ● | |
| Wiper | ● | |
| Seat | Foam seat | |
| Toughened front windshield | ● | |
| Vehicle lamps | Normal light（12V） | |
| High and low speed function | ● | |
| Back light | － | |
| LCD meter | ● | |
| Entertainment system | Speaker | － |
| Player | － | |
| MP3 | － | |
| Reversing image | － | |
| USB charging port | ● | |
| Accessory too | Instructions | － |
| Battery cable | ● | |
| Number of containers | SKD/纸箱 | 39Units/40HQ 12 Units/12GP |
| Note：●Standard ○Optional —none | ||
